August 7, 2025 8 min to read

Installing Kubernetes with Kubespray and Adding Worker Nodes (2025V.)

A comprehensive guide to automated Kubernetes cluster deployment and scaling using Kubespray with Cilium CNI

Reference: Kubespray Deployment Guide

Overview

In this post, we’ll explore how to automatically install and configure a Kubernetes cluster using Kubespray, and further expand it by adding Worker Nodes through hands-on practice. Kubespray is an Ansible-based provisioning tool that allows flexible installation of Kubernetes clusters including HA configurations across various environments (GCP, AWS, on-premises, etc.) by simply defining YAML-based inventory files.

This practical guide covers the following key areas:

• On-premises Control/Worker Node VM configuration
• Kubespray installation and Ansible virtual environment setup
• Cluster inventory definition including Helm, Cilium, and Ingress settings
• Cluster installation through Ansible playbooks (cluster.yml)
• Adding one worker node and scaling configuration through scale.yml

Additionally, we’ll cover essential Kubernetes operational settings including kubectl, bashrc, autocompletion, and context configuration.

System Configuration

Based on July 30, 2025 standards.

Environment Details

Node Specifications

Prerequisites

Before starting the Kubespray installation, you need to prepare your environment.

VM Creation

VMs were created using Cockpit for this deployment.

SSH Key Setup

# Generate SSH key
ssh-keygen

# Update /etc/hosts for easier node access
sudo vi /etc/hosts
10.10.10.17 k8s-control-01
10.10.10.18 k8s-compute-01
10.10.10.19 k8s-compute-02

# Copy SSH key to all nodes
ssh-copy-id k8s-control-01
ssh-copy-id k8s-compute-01
ssh-copy-id k8s-compute-02

# Verify SSH connections
ssh k8s-control-01
ssh k8s-compute-01
ssh k8s-compute-02

Package Installation

# Update package lists and install required packages
sudo add-apt-repository ppa:deadsnakes/ppa
sudo apt-get -y update
sudo apt install -y python3.10 python3-pip git python3.10-venv

# Verify Python version
python3.10 --version

Kubespray Installation and Setup

1. Clone Repository and Setup Environment

# Clone the Kubespray repository
git clone https://github.com/kubernetes-sigs/kubespray.git
cd kubespray

# Copy sample inventory
cp -rfp inventory/sample inventory/somaz-cluster

# Create and activate virtual environment
python3.10 -m venv venv
source venv/bin/activate

# Install dependencies
pip install -U -r requirements.txt

2. Configure Inventory

First, we’ll deploy only k8s-compute-01, then later add k8s-compute-02 using scale.yml.

inventory/somaz-cluster/inventory.ini

[kube_control_plane]
k8s-control-01 ansible_host=10.10.10.17 ip=10.10.10.17 etcd_member_name=etcd1

[etcd:children]
kube_control_plane

[kube_node]
k8s-compute-01 ansible_host=10.10.10.18 ip=10.10.10.18

3. Customize Cluster Configuration

inventory/somaz-cluster/group_vars/k8s_cluster/k8s-cluster.yml

# Choose network plugin (cilium, calico, kube-ovn, weave or flannel)
kube_network_plugin: cilium

# Cluster name
cluster_name: somaz-cluster.local

# Ownership configuration (important for permission issues)
kube_owner: root  # Change from default 'kube' to 'root' to avoid permission issues

inventory/somaz-cluster/group_vars/k8s_cluster/addons.yml

# Helm deployment
helm_enabled: true

# Metrics Server deployment
metrics_server_enabled: true

# The plugin manager for kubectl
krew_enabled: true
krew_root_dir: "/usr/local/krew"

4. Verify Ansible Connectivity

# Test connection to all nodes (run from ~/kubespray directory)
ansible all -i inventory/somaz-cluster/inventory.ini -m ping

5. Deploy Kubernetes Cluster

# Deploy the cluster (run from ~/kubespray directory)
ansible-playbook -i inventory/somaz-cluster/inventory.ini cluster.yml --become

# For background execution
nohup ansible-playbook -i inventory/somaz-cluster/inventory.ini cluster.yml --become &

6. Configure kubectl

# Create kubectl config directory and copy credentials
mkdir ~/.kube
sudo cp /etc/kubernetes/admin.conf ~/.kube/config
sudo chown $USER:$USER ~/.kube/config

7. Setup kubectl Completion and Aliases

# Add kubectl completion and aliases to bashrc
echo '# kubectl completion and alias' >> ~/.bashrc
echo 'source <(kubectl completion bash)' >> ~/.bashrc
echo 'alias k=kubectl' >> ~/.bashrc
echo 'complete -F __start_kubectl k' >> ~/.bashrc

# Apply bashrc changes
source ~/.bashrc

8. Verify Installation

# Check nodes
k get nodes
NAME             STATUS   ROLES           AGE    VERSION
k8s-compute-01   Ready    <none>          2d4h   v1.33.3
k8s-control-01   Ready    control-plane   2d4h   v1.33.3

# Check versions
k version
containerd --version

# Check Cilium image
k get ds cilium -n kube-system -o=jsonpath='{.spec.template.spec.containers[0].image}'

Troubleshooting Cilium Permission Issues

Currently, there’s a known permission error with Cilium. Here’s the fix:

# Fix CNI binary permissions
chown -R root:root /opt/cni/bin

For more information about this issue, see: Cilium GitHub Issue #23838

Alternatively, you can modify the configuration:

inventory/somaz-cluster/group_vars/k8s_cluster/k8s-cluster.yml

# Change from default
# kube_owner: kube

# To
kube_owner: root

Adding Worker Nodes

One of the key advantages of Kubernetes is its scalability. Let’s add k8s-compute-02 to our cluster using the scale.yml playbook.

Reference: Kubespray Scaling Documentation

1. Update Inventory Configuration

inventory/somaz-cluster/inventory.ini

# This inventory describes a HA topology with stacked etcd
[kube_control_plane]
k8s-control-01 ansible_host=10.10.10.17 ip=10.10.10.17 etcd_member_name=etcd1

[etcd:children]
kube_control_plane

[kube_node]
k8s-compute-01 ansible_host=10.10.10.18 ip=10.10.10.18
k8s-compute-02 ansible_host=10.10.10.19 ip=10.10.10.19

[add_node]
k8s-compute-02

2. Run Scale Playbook

# Add new nodes to the cluster using scale.yml
nohup ansible-playbook -i inventory/somaz-cluster/inventory.ini scale.yml --limit add_node --become &

3. Verify Scaled Cluster

# Check all nodes
k get nodes
NAME             STATUS   ROLES           AGE    VERSION
k8s-compute-01   Ready    <none>          2d5h   v1.33.3
k8s-compute-02   Ready    <none>          2d4h   v1.33.3
k8s-control-01   Ready    control-plane   2d5h   v1.33.3

Error Recovery

If you encounter errors during scaling, run the facts playbook first, then retry:

# Run facts playbook to refresh node information
ansible-playbook -i inventory/somaz-cluster/inventory.ini playbooks/facts.yml --become

# Then retry the scale operation
nohup ansible-playbook -i inventory/somaz-cluster/inventory.ini scale.yml --limit add_node --become &

Advanced Operations

Scaling Options

# Scale with all new nodes
nohup ansible-playbook -i inventory/somaz-cluster/inventory.ini scale.yml --become &

# Scale with specific node limit
nohup ansible-playbook -i inventory/somaz-cluster/inventory.ini scale.yml --limit add_node --become &

Node Removal

# Remove specific node
ansible-playbook -i inventory/somaz-cluster/inventory.ini remove-node.yml -b --extra-vars='node=node3' --extra-vars reset_nodes=true

Verification and Monitoring

Cluster Status Verification

# Check all nodes with detailed information
kubectl get nodes -o wide

# Check system pods
kubectl get pods -n kube-system

# Check Cilium status
kubectl get pods -n kube-system -l k8s-app=cilium

# Verify Cilium connectivity
kubectl exec -n kube-system ds/cilium -- cilium status

Sample Application Deployment

# Deploy a test application
kubectl create deployment nginx --image=nginx
kubectl expose deployment nginx --port=80 --type=NodePort

# Check deployment
kubectl get pods
kubectl get services

Conclusion: “Production-Ready Kubernetes Installation Automation with Kubespray”

Kubespray goes beyond simple installation automation to enable production-level Kubernetes cluster configuration. It’s particularly useful in the following scenarios:

• IaC-based infrastructure management through Terraform + Ansible integration
• Automated HA cluster, MetalLB/Ingress configuration
• Quick deployment needs in on-premises or private cloud environments
• Repeated creation and removal of test clusters in CI environments

Through this hands-on practice, we’ve learned how to control clusters using declarative inventory files and Ansible playbooks instead of manually repeating Kubernetes installation processes.

Establishing the flow of Ansible-based automation → Cluster construction → GitOps-based app deployment can elevate operational automation to the next level.
