January 3, 2025 8 min to read

Understanding HTTP and HTTPS Protocols

A comprehensive guide to HTTP, HTTPS, and SSL/TLS implementation

Overview

HTTP (Hypertext Transfer Protocol) and HTTPS (Hypertext Transfer Protocol Secure) are protocols for transmitting data over the internet. Let’s explore their differences and implementation.

HTTP (Hypertext Transfer Protocol)

Concept

Protocol defining data transfer between web browsers and servers
Supports HTML, images, video, audio, and other content types
Transmitted as unencrypted text (security vulnerable)
Default port: 80
URI format: http://example.com

Working Process

Client sends HTTP request message:
- Contains HTTP method (GET, POST, PUT, DELETE)
- Includes request URI
Server processes request and sends response:
- Contains status code (200, 404, 500)
- Includes response body
Client interprets response:
- Processes received data
- Makes additional requests if needed

HTTP Methods

Method	Description	Idempotent	Safe
GET	Request data from a resource	Yes	Yes
POST	Submit data to be processed	No	No
PUT	Update a resource or create if it doesn't exist	Yes	No
DELETE	Remove a resource	Yes	No
PATCH	Apply partial modifications to a resource	No	No
HEAD	Same as GET but returns only headers	Yes	Yes
OPTIONS	Returns supported methods for a resource	Yes	Yes

HTTP Status Codes

Category	Example	Description
1xx (Informational)	100 Continue	Request received, continuing process
2xx (Success)	200 OK	Request succeeded, normal response returned
3xx (Redirection)	301 Moved Permanently	Resource has moved permanently
4xx (Client Error)	404 Not Found	Resource not found on server
5xx (Server Error)	500 Internal Server Error	Server encountered an error

Key Characteristics

Stateless protocol
No storage of previous requests/responses
Uses cookies/sessions for state management
Version evolution:
- HTTP/1.0 (1996): One request per connection
- HTTP/1.1 (1997): Persistent connections, pipelining
- HTTP/2 (2015): Multiplexing, header compression, server push
- HTTP/3 (2022): QUIC protocol, improved performance over unreliable connections

🔒 HTTPS (Hypertext Transfer Protocol Secure)

Concept

Secure version of HTTP
Uses SSL/TLS for encryption
Verifies server identity through certificates
Protects sensitive information
Prevents man-in-the-middle attacks
Default port: 443
URI format: https://example.com
Positive SEO impact (Google ranks secure sites higher)

SSL/TLS Overview

SSL: Developed by Netscape (1995)
TLS: Successor to SSL (1999)
Uses public key encryption
TLS recommended over SSL for security
Essential component of HTTPS
Version evolution:
- SSL 2.0/3.0: Deprecated, considered insecure
- TLS 1.0/1.1: Deprecated as of March 2021
- TLS 1.2: Current widespread adoption
- TLS 1.3: Latest version (2018), improved security and performance

TLS Handshake Process

Client Hello: Client sends supported TLS versions, cipher suites, random number
Server Hello: Server selects TLS version, cipher suite, sends random number
Certificate: Server sends its SSL/TLS certificate
Certificate Verification: Client verifies certificate against trusted CAs
Key Exchange: Client generates pre-master secret, encrypts it with server's public key
Server Acknowledgment: Server decrypts pre-master secret
Session Keys Created: Both sides derive symmetric session keys
Secure Communication: Data encrypted using session keys

Working Process

Client connects to HTTPS server
Client requests server's public key
Server sends SSL/TLS certificate
Client verifies certificate
Client generates session key
Client encrypts session key with server's public key
Server decrypts session key
Secure communication begins

📊 HTTPS Working Process Flowchart

graph TD; A[Client connects to HTTPS server] --> B[Client requests server's public key]; B --> C[Server sends SSL/TLS certificate]; C --> D[Client verifies certificate]; D --> E[Client generates session key]; E --> F[Client encrypts session key with server's public key]; F --> G[Server decrypts session key]; G --> H[Secure communication begins];

Modern HTTPS Security Features

HTTP Strict Transport Security (HSTS)

Forces browsers to use HTTPS only
Prevents downgrade attacks
Implementation via header: Strict-Transport-Security: max-age=31536000

Certificate Transparency (CT)

Public logs of issued certificates
Helps detect unauthorized certificates
Required by major browsers

Certificate Authority Authorization (CAA)

DNS record specifying which CAs can issue certificates
Example: example.com. CAA 0 issue "letsencrypt.org"

Content Security Policy (CSP)

Mitigates XSS and data injection attacks
Controls which resources can be loaded
Implementation via header: Content-Security-Policy: default-src 'self'

Implementation Guide: Apache SSL/HTTPS Certificate

1. Install OpenSSL and Enable SSL Module

# Install OpenSSL
sudo yum -y install openssl

# Verify installation
rpm -qa |grep openssl

# Install mod_ssl
yum install mod_ssl

# Check mod_ssl.so
cd /etc/httpd/modules/
ls mod_ssl*

2. Generate Private Key

openssl genrsa -des3 -out server.key 2048

3. Create Certificate Signing Request

openssl req -new -key server.key -out server.csr

# Required information:
Country Name: KR
State: Seoul
Locality: city
Organization: company
Unit: section
Common Name: somaz
Email: somaz@gmail.com

4. Remove Password from Private Key (Optional)

cp server.key server.key.origin
openssl rsa -in server.key.origin -out server.key

5. Generate Certificate

openssl x509 -req -days 3650 -in server.csr -signkey server.key -out server.crt

6. Copy Certificates

cp server.key /etc/httpd/conf/
cp server.crt /etc/httpd/conf/

7. Configure Apache to Use SSL

# Edit SSL configuration
vi /etc/httpd/conf.d/ssl.conf

# Add or modify these lines
SSLCertificateFile /etc/httpd/conf/server.crt
SSLCertificateKeyFile /etc/httpd/conf/server.key

# Restart Apache
systemctl restart httpd

8. Test Configuration

# Check for configuration errors
apachectl configtest

# Verify SSL is working
openssl s_client -connect yourdomain.com:443

Implementation Guide: Nginx SSL/HTTPS Configuration

server {
    listen 443 ssl;
    server_name yourdomain.com;

    ssl_certificate /etc/nginx/ssl/server.crt;
    ssl_certificate_key /etc/nginx/ssl/server.key;

    # Modern SSL configuration
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-ECDSA-CHACHA20-POLY1305:ECDHE-RSA-CHACHA20-POLY1305;
    ssl_prefer_server_ciphers on;

    # HSTS (optional)
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;

    # Other common security headers
    add_header X-Content-Type-Options nosniff;
    add_header X-Frame-Options SAMEORIGIN;
    add_header X-XSS-Protection "1; mode=block";

    location / {
        root /usr/share/nginx/html;
        index index.html index.htm;
    }
}

# Redirect HTTP to HTTPS
server {
    listen 80;
    server_name yourdomain.com;
    return 301 https://$host$request_uri;
}

Let’s Encrypt for Free SSL Certificates

Let’s Encrypt provides free, automated SSL certificates.

Using Certbot with Apache:

# Install Certbot
sudo apt install certbot python3-certbot-apache

# Obtain and install certificate
sudo certbot --apache -d yourdomain.com

# Auto-renewal (already added to crontab by certbot)
sudo certbot renew --dry-run

Using Certbot with Nginx:

# Install Certbot
sudo apt install certbot python3-certbot-nginx

# Obtain and install certificate
sudo certbot --nginx -d yourdomain.com

# Auto-renewal check
sudo certbot renew --dry-run

HTTP vs HTTPS Comparison

Feature	HTTP	HTTPS
Data Transfer	Plain text	Encrypted
Port	80	443
Security	Vulnerable to eavesdropping	Protected against interception
Authentication	No authentication	Server authentication
Performance	Faster (no encryption overhead)	Slight overhead due to TLS handshake
SEO Impact	Negative (Google prefers HTTPS)	Positive ranking factor
Modern Features	Limited access to new web features	Required for features like Service Workers

Troubleshooting Common SSL Issues

Certificate Issues

Self-signed Certificate: Browser warnings for untrusted certificates
Certificate Expired: Check expiration date with openssl x509 -in server.crt -noout -enddate
Common Name Mismatch: Certificate must match domain name exactly or use wildcard
Incomplete Certificate Chain: Ensure intermediate certificates are included

Configuration Issues

Mixed Content: HTTP resources loaded on HTTPS page
Cipher Suite Incompatibility: Check with openssl ciphers -v
Protocol Version Issues: Ensure modern TLS versions are enabled
Certificate File Permissions: Private keys should be readable only by server process

Diagnostic Tools

SSL Labs Server Test
DigiCert SSL Checker
Command line: openssl s_client -connect example.com:443 -tls1_2
Browser DevTools: Check Security panel for certificate details
